High Frequency 13.56 RFID antenna NFC phone reader with network port
The TSK65xx & TSK85xx RFID Reader is a usb rfid reader for access control, it can be 125KHz or 13.56MHz as your demand, output format can be Wiegand 26/34; RS232; RS485 , popular used in enterprises management, housing management etc.
TSK6510 | TSK6520 | TSK6540 | TSK6560 | TSK6580 | TSK6590 | |
Frequency | 125KHz/13.56Mhz | |||||
Supporting Card | EM4100 card serial number ,ISO/IEC14443A/B, ISO15693 & ISO18092 | |||||
Read Distance | > 8cm(Depending on label sizeand surroundings) | |||||
Interface | Wiegand26/34,RS232,RS485,ABA (TVS transient pulse protection) | |||||
Power Supply | DC9V ~ 12V | |||||
Current | <50mA | |||||
Working Distance | >100m(Using the national standard Cat5e network cable, test results without interference) | |||||
Protection Level | IP65 epoxy resin embedment | |||||
Operating Temperature | -10ºC ~ 70ºC | |||||
Storage Temperature | -20ºC ~ 80ºC | |||||
Humidity | 0 ~ 95% | |||||
Dimension | 111*70*14mm | 80*43*13mm | 118*76*22mm | 105*47*23mm | 122*75*20mm | 122*45*20mm |
125Khz /ISO7815 | EM4100 / H4100/ EM4200/ TK4100/EM4102 / H4102/EM4105/EM4305/EM4450/ATA5577/Hitag2/Hitag S 256 |
| ISO / IEC 14443 A ,ISO / IEC 14443 B &ISO / IEC 15693 | M 1K S50 / MF1 S50,M 4K S70 / MF1 S70,M Plus S2K,M Plus S4K,Ntag203,Ultralight,Ultralight c,DesFire EV1 8K(MF3 IC D81),DesFire 4K (MF3 IC D40),DesFire EV1 4K (MF3 IC D41),SRI512,I.code SLI SI2 / I.code 2,I.code SLI-S,I.code SLI-L,Tag-IT Ti2048,Tag-IT Ti256 |
Our TSK65xx & TSK85xx serial readers include ISO14443A/B; ISO15693;
ISO18092 standards products, with RS232/ USB / WIFI+ TCP/IP
outputs, pls feel free to inquire us online for more details and prices !
Related products range:
(Chips and sizes and material can be customized)
1.RFID card,PVC card
2.RFID keyfob
3.RFID Wristband
4.RFID label/sticker,NFC tag
5.RFID inlay(rfid wet/dry inlay)
6.RFID Reader (125Khz,13.56Mhz,860-960Mhz)
7. 134.2Khz RFID Handheld Reader for animal tracking
8. RFID Blocking Sleeve / wallet/ holder
9.RFID Glasss Capsule Tag
10.RFID guard tour system
Company Advantages
1)The biggest manufacturer of RFID cards in China
2)Outstanding design and development team
3)Good manufacturing practice workshop
4)Best quality control and competitive price
5)Fast delivery and safe shipping way.
Customer Satisfaction:
1)Excellent aftersale service
2) Repair guarantee: Within one year after products purchased, Sencan will provide you with free repair service
3)Feedback quickly: 24 hours online service and reply to your inquiry within 8 hours
4)We can provide online supports for you when need helps on testing
Fast Delivery Time
Delivery time: samples for 1-3 working days, order for 3-7 working days
